Mutoh XpertJet XPJ-1682WR PRO sublimation printer

MUTOH: Japanese precision and constant development

Mutoh is one of the world's leading manufacturers of wide-format digital printers and cutting plotters, which are all designed and manufactured exclusively in Japan, from the consumables to the very last screw. With numerous sales points in Europe, the Middle East and Africa, the brand name is now synonymous with stable quality and reliability.

Japanese Mutoh values precision and high quality through craftmanship – in contrast to the accelerated production which results in poor quality typical of Chinese brands. From the engineering design of new products, through the assembly by expert colleagues, to the improvement of existing products, the entire process implements the Japanese Kaizen philosophy, the central idea of ​​which is the pursuit of continuous improvement. The company, founded in 1952, is therefore not stuck in the past: with seventy years of experience behind them, they are constantly working to provide state-of-the-art technological solutions.

Better than ever print quality with double AccuFine printhead

Mutoh has been integrating piezo printheads since 1999. Due to decades of experience and continuous development, their printheads are now worthy opponents of the most well-known brands. The updated “PRO” model of Mutoh XpertJet 1682WR sublimation printer is equipped with two, staggered, new generation, 3200-nozzle AccuFine HD printheads, which ensure best in class drop placement accuracy even at high printing speed. Contrary to conventional printheads, AccuFine printheads have a higher density nozzle pitch contributing to higher image quality, and an increased nozzle row length, which enables higher productivity. Due to this development, Mutoh XpertJet 1682WR PRO can be print at an outstanding speed of up to 113,8 m²/h, the lowest available print resolution is 300x600dpi and the highest available print resolution is 1200×1200dpi.

Four head heights are available ranging from 1.5 to 4 mm, which provides wide media compatibility. The Piezo Variable Drop Technology ensures perfect coverage and precise ink landing from the thinnest to the thickest materials.

Intelligent features for smooth workflow

Mutoh XpertJet 1682WR PRO sublimation printer provides high level of user comfort and stable production with its built-in intelligent features.

• DropMaster2: Ensures automated bi-directional alignment across varying media thicknesses, delivering precise
  prints without manual adjustments.
• FeedMaster: Provides automated media feed adjustments, ensuring smooth, consistent media feeding for optimal print accuracy and reducing the need for manual corrections.
• Nozzle Area Select: Eliminates downtime and provides uninterrupted printing by automatically selecting only active nozzle blocks in the event missing nozzles cannot be recovered.
• Media Tracker: Prints a barcode on each roll before it is removed. Upon reloading, a laser scans the barcode to accurately measure the remaining media, eliminating guesswork and preventing disruptions during printing.

Motorised Take-up System

To optimize workflow and increase productivity, you can setup Mutoh Xpertjet 1682WR PRO with a motorized torque controlled take-up system, which is linked to the printer and follows the start and stop of printing.

You can choose from the following options to best suit your printing needs:

• 40 kg / ∅250 mm take-up system
• 100 kg / ∅250 mm take-up system

Optimize the performance of your Mutoh printer: VerteLith™ RIP software

VerteLith™ RIP software is optionally available for the printer. It is specially developed by Mutoh for their printers, which allows you to maximize the capabilities of your printer:

• A features list unmatched in its category (printer statuses, color management, pre-production tools, soft proofing, post-processing preparation tools, etc.)
• User-friendly interface, simple workflow
• Fast RIP processing for both PDF and PostScript files
• „Mutoh Clear Tone” technology: outstandingly smooth color gradients
• Perfect handling of transparencies and spot colors
• Built in „Mutoh CMYK” ICC profile to maximize gamut
• Professional profiling tools
• Multi language chat support

VerteLith™ has won the prestigious EDP Award in 2021, recognizing it as “ideal for smaller print shops" which "offers functionality that you will find only at expensive RIP's from independent RIP vendors."

Full Service

Since we plan with our customers for the long term, it is important for us to support our customers as a reliable partner from the decision making to the post-warranty service. Our Full Service means that the prices of our machines include everything:

• Needs assessment, product presentation, quotation
• Delivery and installation within Hungary, commissioning and training
• After-sales support and service (without annual service fee!)
• Plus: post-warranty service at a favorable price
