Name: Audley SUB 180 PRO roll to roll sublimation printing system 180cm
Brand: Audley
SKU: 102-002
Price: 6965.08 EUR

Sublimation

Sublimation wide format printing is similar to desktop “sublimation” printers, using dye sublimation inks, which can be printed on special roll sublimation paper with a wide format printer. Graphics and prints printed on paper can be transferred by heat press or roll heat treatment calender onto textiles with at least 80% synthetic fibres (e.g. polyester), or onto hard products and souvenirs pre-treated with sublimation varnish. The dye is transformed into a vapour by the heat treatment, so that the dye vapour is directly transferred into the molecular structure of the fibre material, thus colouring the substrate. Sublimation technology is used to produce, among other things, dresses, swimwear, jerseys, fitness clothing, flags, cushions, curtains, textile pictures, textile display products, small and large hard goods, souvenirs.

Advantages of sublimation technology

Tactile, soft print
Beautiful, sharp and vivid colours
Outstanding scratch-, water- and wash resistance
Continuous and flexible printing in large format with roll-to-roll technology

AUDLEY SUB 180 PRO roll-to-roll sublimation printer

If you value affordability, quality, economical solutions and productivity, choose Audley! If you're planning to start large format printing production, or to expand your capacity, the best value for money wide format printer Audley 180 SUB PRO sublimation printer with dual Epson i3200 printheads. You could print on rolls of fabric as wide as 180 cm!

Audley SUB 180 PRO roll-to-roll sublimation printing system contains

Dual Epson i3200 printheads
Adjustable strength media feed rollers
Improved offset head and cap position for perfect print quality
Dual X+Y professional servo motor
High capacity intelligent drying unit
Roller feedstock collecting device
+ free InkTec G7 sublimation ink starter pack

EPSON i3200 print head: more beautiful prints and 70% faster than the Epson DX5

Audley SUB 180 PRO is equipped with dual i3200 heads for guaranteed speed, quality and stability. The i3200 has 4 in a row, 800 nozzles, so a total of 3200 nozzles are 40-70% faster than the DX5. The ink droplets are shaped in a more regular circle compared to the dx5 but more importantly: ink droplets are smaller, so the print quality is better, sharper and more contoured.

	Epson i3200	Epson DX5
Number of nozzles (more = faster)	3200	1440
Resolution npi/2lines (bigger = better)	600	360
Droplet size (smaller = better)	2.5	3.5
Printing speed standard 4pass	26 m²/h	15 m²/h
Lifespan	~2years	~2years

Lifetime depends on both the frequency and measure of usage, therefore this data serves informational purposes only.

InkTec G7 professional sublimation ink

The basic pillar of sublimation wide format printing is the right ink, specially manufactured or calibrated and tested for the specific printheads (in this case the Epson i3200) InkTec is one of the leading ink manufacturers on the market. This is due to its excellent colour gamut, high quality for fast printing, environmentally friendly formulation and outstanding price.

Perfect colour coverage – even better than EPSON!

Colour accuracy is one of the most important criteria for good production. For a given paint, the colour gamut determines the amount of colour shades it can “display, produce”. InkTec's inks, in this case the G7 type, cover almost identical colour gamuts in the in-house tests, and even outperform EPSON's factory Ultrachrome DS inks for certain colours. On top of it it's also environmentally friendly:

Has the Oeko Tex / Eco Passport certification
VOC and Formaldehyde free
RoHS compliance (does not contain harmful, hazardous substances)

Are you interested?

Request DEMO printing appointment and learn more about the most popular roll-to-roll sublimation printer with the help of our professionally trained staff!
